KJDS 420

Dizel Jeneratörler / KJSD420 / kVA - kVA

GROUP
Stand-by Power	420 (336)	kVA (kW)
Prime Power	378 (302)	kVA (kW)
Power Factor	0,8	Cos Phi
Frequency	50	Hz
Sound Level	70	dBA 7m
Guarantee	2 years / 1000 hours	-

ENGINE
Make	SDEC	-
Model	G128AZLD4	-
Engine Type	-	-
Speed	1500	rpm
Prime Power	387,9	kW (HP)
Stand-by Power	431	kW (HP)
Number of Cylinders	12	-
Cylinder Combination	12 V	-
Air Indication System	Intercooler	-
Cooling System	Water Cooled	-
Starting System	-	-
Governor Type	Electronic	-
Cylinder Displacement	16,2	lt
Bore ve Stroke	144x165	mm
Compression Ratio	17, 5:1	-
Electric System	24V(DC) 105A
Fuel Consumption %100 Loaded	85	lt / h
Fuel Consumption %75 Loaded	68	lt / h
Fuel Consumption %50 Loaded	49	lt / h
Fuel Tank Capasity	500	lt
Fuel Type	Diesel	-
Oil Capacity		lt
Sparkplug Properties		-
Oil Type	25W40	-
Low Oil Alarm	Available	-
Overload Alarm	Available	-
Voltmeter	Available	-
Cabine Type	KB8	-
Panel Type		-
DC Voltage	12 V	-

ALTERNATOR
Make	SKN	-
Model	SKND-420	-
Type	Senkron, Brushless	-
Prime Power	380	kVA (kW)
Stand-by Power	420	kVA (kW)
Overloaded	1 hour per 12 hours %110 , 2 minute %120	-
Insulation Resistance	Min. 1800 Volt	V
Short Circuit Current	%300 10 seconds	-
Isolation Class	H	-
Drip Proof	IP 23	-
Voltage	231 / 400	V
Tolerance of Voltage	%0,5	-
Continuous Circuit		A
Phase Number	3	-
Pole Number		-

DIMENSIONS
Width (None-Cabine / Cabine)	1240(1240)	mm
Length (None-Cabine / Cabine)	1550(1550)	mm
Height (None-Cabine / Cabine)	2200(2400)	mm
Weight (None-Cabine / Cabine)	3750(3950)	kg

WELDING
Continuous Welding Circuit	-	A
Circuit Regulation Range	-	A
Priming Voltage	-	V
Idle Welding Voltage	-	V
